Cold Storage

Good Quality High Speed Cold Storage Door

High speed cold storage door is designed for cold storage environments, offering excellent thermal insulation, frost resistance, and energy efficiency. ?With a multi-layer composite thickened door curtain filled with thermal insulation materials, it reduces heat transfer and minimizes energy loss. ?The door features airtight sealing, wind resistance, and a built-in servo tube mounted motor for high precision and faster opening speed. ?

Brand VICTORY

product details

Application

VICTORY speed freezer door series is an excellent choice for cold storage doors, thermal insulation, frost resistance, cold protection; double base fabric, filled with fibrous thermal insulation material, has a super thermal insulation effect; high-speed opening and closing, the maximum reduction of cold storage Internal and external air circulation reduces energy loss.

Product Parameter

Basic parameters
Open speed	?0.8-1.2m/s
Close speed	?0.6-1.0m/s
Door frame material	?2.0mm steel frame with powder coated.
Curtain material	?0.9mm PVC and 3.0mm foamed inter-filling
Roller bearing	steel shaft and steel pipe material
Transparent window	?available but not recommend
Fire-proof	?German DIN4102 standard class2
Sealing performance	?brush type with strong nylon material
Manual function	?reserve power supply for power failure use

Product features

The conventional features of Thermal Insulation High Speed Door include:

1. Insulation: Multi-layer composite thickened door curtain, filled with thermal insulation materials, which significantly reduces heat transfer

2. Airtight: double-row brushes or rubber bands in the track are sealed in a cassette to block air convection and promote heat preservation

3. Wind resistance: the built-in aluminum alloy profile of the curtain is resistant to wind pressure and impact, which enhances the integrated aesthetics of the curtain

4. Drive: Built-in servo tube mounted motor, higher precision, larger roller, faster door opening speed

5. Frame: SUS304 stainless steel frame and components, corrosion resistant and easy to clean, more suitable for cold storage environment

6. Safety: standard infrared safety anti-pinch protection device, optional wireless airbag bottom edge (patented technology)

7. Anti-freezing: optional rail heating system device to prevent condensation and icing.
